Why do satellites not fall?

December 9, 2022

Simple questions and UTokyo
An introduction to academia starting with “Why?”

After making a list of questions which would pique anyone’s interest, we asked faculty members on campus who might be knowledgeable in these areas to answer them from the perspective of their respective expertise. Let’s take a look into the world of research through questions that you feel you know something about, but cannot answer definitively when actually asked.

Q5. Why do satellites not fall?

After being launched into space, satellites continue to orbit the Earth. Why do they not fall to the ground?
A. Actually, they are in a constant state of falling.
Answered by Hiroyuki Koizumi
Associate Professor, Graduate School of Frontier Sciences
Depiction of the EQUULEUS CubeSat (engineering model), equipped with the AQUARIUS water-vapor propulsion system, making observations from the far side of the Moon. It was launched aboard a NASA-developed rocket on November 16, 2022. ©NASA

If there are no obstacles, they will keep flying

Satellites orbit the Earth at tremendous speeds while they continuously fall. The most important factor affecting their flight is the presence or lack of obstacles. As long as there is nothing to obstruct them, they can keep moving. For example, if you dig a hole from Japan to Brazil to create a vacuum tunnel and drop a ball into it, the ball will continue to fall with increasing speed and finally reach the center of the Earth since there are no obstacles. Because there is nothing in the center of the Earth that would stop the ball, the momentum keeps it going to the Brazilian side. When it reaches the surface of Brazil, gravity applies the brake, and the ball slows down and stops. Then it falls toward the center again, repeating this back and forth. Satellites continue to fall in the same way.

Why don’t they fall to the ground? This is because satellites have velocity horizontal to the Earth. If a satellite with no velocity were to be plunked down in space, it would fall to the ground very quickly. However, by launching a satellite to a height where there are no obstacles and pushing it out with speed in a horizontal direction, it will orbit the Earth without dropping downwards.

In other words, the essential requirement is to come up with a speed and height that would put the satellite into an orbit where it wouldn’t hit any obstacles. For spacecraft that orbit close to the Earth at an altitude of around 400 km, such as the International Space Station (ISS), a speed of just under 8 km per second is necessary. At this speed, one could complete a full marathon in about 5 seconds. At about 400 km altitude, there is still a small amount of atmosphere, and the satellite will gradually fall to the Earth because of atmospheric drag. Hence, the ISS adjusts its orbit by occasionally firing the thrusters. The more distant the satellite is from the Earth, the thinner the atmosphere gets. For example, if the satellite is at an altitude of 1,000 km, it will not fall for about 1,000 years even if left alone.

Focusing on space propulsion systems that use water as propellant

I am researching space propulsion systems, which are an integral part of these satellites. To accelerate an object, something must be pushed. For example, when we walk, we push the ground. Airplanes accelerate by pushing the air. The propulsion system is the pushing device. Since there is nothing to push around in space, space propulsion accelerates by throwing off its own mass (propellant); this is called rocket propulsion. There are many different types, but I focus on propulsion that uses water as the propellant. The simplest type is one that uses water vapor as the pushing power, as it spreads out when liquid water is turned into vapor. Another is the ion propulsion used in the Hayabusa spacecraft, which ionizes water vapor into a state called plasma and pushes it out by applying a voltage to it.

The AQUARIUS micropropulsion system, which uses water as propellant. Launched on November 16, 2022, aboard EQUULEUS. Alumni who led the development of AQUARIUS launched a startup, Pale Blue, in 2020 to develop and produce propulsion systems that use water as a propellant.
Miniature ion thruster developed by Associate Professor Koizumi alongside a one-yen coin (the thruster is the part of a propulsion system that generates thrust).

The advantage of water is that it is easy to handle and procure. In recent years, many different companies have been entering the space industry. We see significant advantages for these new players in using water, which is non-toxic. As water has been found on the Moon and Mars, it may become possible to source it in space. We can easily have our own personal satellites, fly space probes, and go to space. This may sound like a science fiction world, but I am envisioning such a future.

Associate Professor Koizumi’s book
Jinrui ga Motto Tooi Uchu e Iku tame no Rocket Nyumon (“Introduction to Rockets to Help Humankind Go Farther into Space”) (Impress, 2021)
This book provides basic knowledge about space and rockets. The book also explains the mechanisms of satellites and rocket propulsion using illustrations and images for easy understanding.



* This article was originally printed in Tansei 45 (Japanese language only). All information in this article is as of September 2022.
